ZONESUN ZS-YTEXW1 ATEX Semi-automatic Explosion Proof Acetone Industrial Gasoline Flammable Liquids Filling Weighing Machine

Voltage
Price
Regular price $3,199.00 USD
Regular price Sale price $3,199.00 USD
Save $-3,199 USD
/
  • One Year Warranty
  • User Manual
  • One-to-one Video Chat Support
  • Install & Debug Video
  • Custom Package Solution
  • Local Service Location (Romania /Serbia /Kazakhstan/Mexico/Indonesia)

This filling weighing machine has compact machine and it is designed for filling large volumes of flammable liquid products like thinners, cleaning agent, greasing agent into gallon bottles. This weighing filling machine needs to work with the feeding pump to realize filling material feeding.

Parameter

  • Machine model: ZS-YTEXW1
  • Machine voltage: 110/220V 50-60HZ 100W
  • Filling range: 10-30L
  • Working capacity: 3-6 BPM(based on filling volume)
  • Filling accuracy: ±1%
  • Air source: 0.5MPa ± 0.1MPa
  • Air consumption: 5m³/h
  • Weighing range: ≤30kg
  • Machine dimension: About 800*650*1450mm
  • Machine weight: About 100kg
explosion proof filling machine
application of Ex-proof filling machine
parameter of Ex-proof filling machine

Ex-proof control box of Ex-proof filling machine

Explosion Proof Control Box
This is designed to contain any ignition within the box, preventing it from igniting the surrounding hazardous atmosphere.

weighing scale of Ex-proof filling machine

Weighing Scale
Accurate weighing, reducing errors and improving weight accuracy.

discharge outlet of Ex-proof filling machine
A Spray-proof Discharge Outlet
Enables fast loading without jamming or clogging, thereby improving work efficiency.
multiple filling nozzles of Ex-proof filling machine
Multiple Filling Nozzles
Various filling nozzles can be optionally selected, ensures filling accuracy and working capacity.
ATEX filling machine for acetone
