ZONESUN XL-T803 Semi-automatic Model PET Plastic Model Arc Surface Flat Bottle Sticker Labeling Machine

Regular price $2,796.13 $0.00

Parameter
Labeling capacity  +- 0.5mm
Labeling speed    15-30pcs/min
Suitable bottle size:
height:    20mm-200mm
width:     20mm-180mm
Suitable label size
length : 15mm-150mm
width  15mm-150mm
Machine size   980x460x960mm
Power supply   220V/50Hz
Machine weight    41kgs
Label inner diameter   76mm
Label outer diameter  not more than 300mm

Application
Labeling is carried out by means of suction and sticking to achieve labeling on the plane of various work pieces, such as cosmetic flat bottles, packaging boxes, plastic cover labeling, etc.
Change the labeling mechanism, which can be applied to uneven surface labeling, such as labeling of concave planes and circular planes.

Notice:
1.Optional matching ribbon printer and jet printer, labeling at the same time print production batch number, production date, expiration date and other information, labeling, one-step completion of coding, greatly improving production efficiency.
2.It need to custom the fixture to apply to the labeling of various irregular work pieces.(please send you bottle or measure your bottle size )
3.We can custom the machine to apply your label and bottle . please contact with us
